Analysis settings

analysis_settings.json controls how a single analysis is run — the number of samples, the model settings selections, and which outputs (summaries and ORD tables) to produce. It is validated by ods_tools against analysis_settings_schema.json. Nested objects (e.g. gul_summaries, and its ord_output) are expanded into their own subsections below.

The ord_output flags select which result tables to produce; each maps to a table in the ORD standard (e.g. ept_full_uncertainty_oep → the EPT, elt_sample → the SELT).

Field	Type	Required	Constraints	Description
version	string		minimum 3	The schema version for analysis settings validation (optional)
oed_version	string			The OED schema version of the file - ‘major, minor, patch’ format i.e. (2.0.0 or v2.0.0 or “latest version”)
source_tag	integer / string			Labels the origin of the analysis.
analysis_tag	integer / string			Labels the analysis with an identifier.
model_supplier_id	string	Yes		Identifier for the model vendor/module supplier.
model_name_id	string	Yes		Identifier for the model.
number_of_samples	integer		default 100; minimum 0	The number of samples generated per event.
gul_threshold	number		default 0; minimum 0	The threshold at which groun-up losses will be capped.
return_periods	array[integer]			List of return periods as integers ‘[10, 100, 1000 .. etc]’
event_ids	array[integer]			List of event ids as integers ‘[1, 5, 123 .. etc]’
event_ranges	string			Comma separated ist of event id ranges using hyphens as string ‘1-4,8,89-94 .. etc’
peril_filter	array[string]			List of OED peril ids ‘[‘WSS’, ‘WTC’ .. ]’
quantiles	array[number]			List of quantiles as float values ‘[0.0, 0.2, 0.4 .. etc]’
computation_settings	object			List of oasislmf package settings, options are dependent on the package version. To see these look at releases 2.4.0 and up (https://github.com/OasisLMF/OasisLMF/releases)
model_settings	object	Yes		Model specific settings.
vulnerability_adjustments	object			Object containing vulnerability adjustments and replacements.
join_summary_info	boolean		default False	If true, joins the summary info file data to any output files generated
gul_output	boolean		default False	If true generate ground-up loss outputs as per specified gul-summaries.
gul_summaries	array[object]			Specified which outputs should be generated for which summary sets, for insured losses.
il_output	boolean		default False	If true generate insured loss outputs as per specified il-summaries.
il_summaries	array[object]			Specified which outputs should be generated for which summary sets, for insured losses.
ri_output	boolean		default False	If true generate reinsurance net loss outputs as per specified ri-summaries.
ri_summaries	array[object]			Specified which outputs should be generated for which summary sets, for insured losses.
ri_inuring_priorities	array[integer]			Request output at intervening inuring priorities specified as list of integers ‘[1, 3, 4 .. etc]’
rl_output	boolean		default False	If true generate all the reinsurance loss outputs as per specified rl-summaries.
rl_summaries	array[object]			Specified which outputs should be generated for which summary sets, for insured losses.
rl_inuring_priorities	array[integer]			Request output at intervening inuring priorities specified as list of integers ‘[1, 3, 4 .. etc]’
full_correlation	boolean		default False	If true generate losses for fully correlated output, i.e. no independence between groups, in addition to losses for default output.
pla	boolean		default False	If true apply post loss amplification/reduction to losses.
do_disaggregation	boolean		default True	Set whether to split terms and conditions for aggregate exposure (optional)
pla_secondary_factor	number		default 1; minimum 0; maximum 1	Secondary factor to apply to post loss amplification/reduction factors.
pla_uniform_factor	number		default 0; minimum 0	Uniform factor to apply across all losses.

model_settings

Model specific settings.

Field	Type	Required	Constraints	Description
use_random_number_file	boolean			If true use a pre-generated set of random number, if false generate random numbers dynamically.
event_set	string		default 1	Identifier for the event set file that is used for output calculations.
event_rates_set	string		default 1	Identifier for the event rates set file that is used for output calculations.
event_occurrence_id	string		default 1	Identifier for the event occurrence file that is used for output calculations.
footprint_set	string		default 1	Identifier for the footprint files that are used for output calculations.
vulnerability_set	string		default 1	Identifier for the vulnerability files that are used for output calculations.
pla_loss_factors_set	string		default 1	Identifier for the Lossfactor file used for PLA (Post Loss amplification).
correlation_settings	array[object]			The Correlation Settings

model_settings.correlation_settings

Field	Type	Required	Constraints	Description
peril_correlation_group	integer			The Peril Correlation Group
hazard_correlation_value	string			The Correlation Value for harard sampling
damage_correlation_value	string			The Correlation Value for vulnerability sampling

vulnerability_adjustments

Object containing vulnerability adjustments and replacements.

Field	Type	Required	Constraints	Description
adjustments	object			Dictionary containing vulnerability adjustments with vulnerability ID as integer keys and adjustment factors as float values.
replace_data	object			Detailed vulnerability replacements.
replace_file	string			Path to a CSV file containing vulnerability data to be replaced.

gul_summaries

Field	Type	Required	Constraints	Description
id	integer	Yes	minimum 1	Identifier for the summary set.
oed_fields	array[string]			A list of OED fields used to group the generated losses.
summarycalc	boolean		default False	Legacy - (oasis 2.4.x and older) If true, output summary calculations by level for the summary set.
eltcalc	boolean		default False	Legacy - (oasis 2.4.x and older) If true, output the event loss table by level for the summary set.
aalcalc	boolean		default False	Legacy - (oasis 2.4.x and older) If true, output the average annual loss by level for the summary set.
aalcalcmeanonly	boolean		default False	Legacy - (oasis 2.4.x and older) If true, output the average annual loss by level for the summary set without calculating the standard deviation.
pltcalc	boolean		default False	Legacy - (oasis 2.4.x and older) If true, output the period loss table by level for the summary set.
lec_output	boolean		default False	Legacy - (oasis 2.4.x and older) If true, output loss exceed curves by level for the summary set.
leccalc	object			Legacy - (oasis 2.4.x and older) Specifies which loss exceedence curve types will be outputed for the summary level
ord_output	object			ORD output settings

gul_summaries.leccalc

Legacy - (oasis 2.4.x and older) Specifies which loss exceedence curve types will be outputed for the summary level

Field	Type	Required	Constraints	Description
return_period_file	boolean		default False	Legacy - (oasis 2.4.x and older) If true, a file listing the return periods will be provided as part of the analysis inputs. If false, a default set will be used.
full_uncertainty_aep	boolean		default True	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the full uncertainty aggregate loss exceedence curve by level for the summary set.
full_uncertainty_oep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the full uncertainty occurrence loss exceedence curve by level for the summary set.
wheatsheaf_aep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the wheatsheaf aggregate loss exceedence curve by level for the summary set.
wheatsheaf_oep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the wheatsheaf occurrence loss exceedence curve by level for the summary set.
wheatsheaf_mean_aep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the wheatsheaf mean aggregate loss exceedence curve by level for the summary set.
wheatsheaf_mean_oep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the wheatsheaf occurrence loss exceedence curve by level for the summary set.
sample_mean_aep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the sample mean aggregate loss exceedence curve by level for the summary set.
sample_mean_oep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the sample occurrence loss exceedence curve by level for the summary set.

gul_summaries.ord_output

ORD output settings

Field	Type	Required	Constraints	Description
elt_sample	boolean		default False	Sample Event Loss Table (ORD Output flag)
elt_quantile	boolean		default False	Quantile Event Loss Table (ORD Output flag)
elt_moment	boolean		default False	Moment Event Loss Table (ORD Output flag)
plt_sample	boolean		default False	Sample Period Loss Table (ORD Output flag)
plt_quantile	boolean		default False	Quantile Period Loss Table (ORD Output flag)
plt_moment	boolean		default False	Moment Period Loss Table (ORD Output flag)
alt_period	boolean		default False	Period Average Loss Table (ORD Output flag)
alt_meanonly	boolean		default False	Average Loss Table with no standard deviation calculation (ORD Output flag)
alct_convergence	boolean		default False	Average Loss Convergence Table (ORD Output flag), requires alt_period set to true
alct_confidence	number		default 0.95; minimum 0.0; maximum 1.0	Set confidence level for ALCT
ept_full_uncertainty_aep	boolean		default False	Exceedance Probability Table (option), when enable this metric is added to the EPT file
ept_full_uncertainty_oep	boolean		default False	Exceedance Probability Table (option), when enable this metric is added to the EPT file
ept_mean_sample_aep	boolean		default False	Exceedance Probability Table (option), when enable this metric is added to the EPT file
ept_mean_sample_oep	boolean		default False	Exceedance Probability Table (option), when enable this metric is added to the EPT file
ept_per_sample_mean_aep	boolean		default False	Exceedance Probability Table (option), when enable this metric is added to the EPT file
ept_per_sample_mean_oep	boolean		default False	Exceedance Probability Table (option), when enable this metric is added to the EPT file
psept_aep	boolean		default False	Per Sample Exceedance Probability Table, (option) when enable this metric is added to the PSEPT file
psept_oep	boolean		default False	Per Sample Exceedance Probability Table (option), when enable this metric is added to the PSEPT file
return_period_file	boolean		default False	If true, a file listing the return periods will be used for EPT and PSEPT files. If false, a default set will be used.
parquet_format	boolean		default False	Write output files in parquet format rather than csv format.

il_summaries

Field	Type	Required	Constraints	Description
id	integer	Yes	minimum 1	Identifier for the summary set.
oed_fields	array[string]			A list of OED fields used to group the generated losses.
summarycalc	boolean		default False	Legacy - (oasis 2.4.x and older) If true, output summary calculations by level for the summary set.
eltcalc	boolean		default False	Legacy - (oasis 2.4.x and older) If true, output the event loss table by level for the summary set.
aalcalc	boolean		default False	Legacy - (oasis 2.4.x and older) If true, output the average annual loss by level for the summary set.
aalcalcmeanonly	boolean		default False	Legacy - (oasis 2.4.x and older) If true, output the average annual loss by level for the summary set without calculating the standard deviation.
pltcalc	boolean		default False	Legacy - (oasis 2.4.x and older) If true, output the period loss table by level for the summary set.
lec_output	boolean		default False	Legacy - (oasis 2.4.x and older) If true, output loss exceed curves by level for the summary set.
leccalc	object			Legacy - (oasis 2.4.x and older) Specifies which loss exceedence curve types will be outputed for the summary level
ord_output	object			ORD output settings

il_summaries.leccalc

Legacy - (oasis 2.4.x and older) Specifies which loss exceedence curve types will be outputed for the summary level

Field	Type	Required	Constraints	Description
return_period_file	boolean		default False	Legacy - (oasis 2.4.x and older) If true, a file listing the return periods will be provided as part of the analysis inputs. If false, a default set will be used.
full_uncertainty_aep	boolean		default True	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the full uncertainty aggregate loss exceedence curve by level for the summary set.
full_uncertainty_oep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the full uncertainty occurrence loss exceedence curve by level for the summary set.
wheatsheaf_aep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the wheatsheaf aggregate loss exceedence curve by level for the summary set.
wheatsheaf_oep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the wheatsheaf occurrence loss exceedence curve by level for the summary set.
wheatsheaf_mean_aep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the wheatsheaf mean aggregate loss exceedence curve by level for the summary set.
wheatsheaf_mean_oep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the wheatsheaf occurrence loss exceedence curve by level for the summary set.
sample_mean_aep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the sample mean aggregate loss exceedence curve by level for the summary set.
sample_mean_oep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the sample occurrence loss exceedence curve by level for the summary set.

il_summaries.ord_output

ORD output settings

Field	Type	Required	Constraints	Description
elt_sample	boolean		default False	Sample Event Loss Table (ORD Output flag)
elt_quantile	boolean		default False	Quantile Event Loss Table (ORD Output flag)
elt_moment	boolean		default False	Moment Event Loss Table (ORD Output flag)
plt_sample	boolean		default False	Sample Period Loss Table (ORD Output flag)
plt_quantile	boolean		default False	Quantile Period Loss Table (ORD Output flag)
plt_moment	boolean		default False	Moment Period Loss Table (ORD Output flag)
alt_period	boolean		default False	Period Average Loss Table (ORD Output flag)
alt_meanonly	boolean		default False	Average Loss Table with no standard deviation calculation (ORD Output flag)
alct_convergence	boolean		default False	Average Loss Convergence Table (ORD Output flag), requires alt_period set to true
alct_confidence	number		default 0.95; minimum 0.0; maximum 1.0	Set confidence level for ALCT
ept_full_uncertainty_aep	boolean		default False	Exceedance Probability Table (option), when enable this metric is added to the EPT file
ept_full_uncertainty_oep	boolean		default False	Exceedance Probability Table (option), when enable this metric is added to the EPT file
ept_mean_sample_aep	boolean		default False	Exceedance Probability Table (option), when enable this metric is added to the EPT file
ept_mean_sample_oep	boolean		default False	Exceedance Probability Table (option), when enable this metric is added to the EPT file
ept_per_sample_mean_aep	boolean		default False	Exceedance Probability Table (option), when enable this metric is added to the EPT file
ept_per_sample_mean_oep	boolean		default False	Exceedance Probability Table (option), when enable this metric is added to the EPT file
psept_aep	boolean		default False	Per Sample Exceedance Probability Table, (option) when enable this metric is added to the PSEPT file
psept_oep	boolean		default False	Per Sample Exceedance Probability Table (option), when enable this metric is added to the PSEPT file
return_period_file	boolean		default False	If true, a file listing the return periods will be used for EPT and PSEPT files. If false, a default set will be used.
parquet_format	boolean		default False	Write output files in parquet format rather than csv format.

ri_summaries

Field	Type	Required	Constraints	Description
id	integer	Yes	minimum 1	Identifier for the summary set.
oed_fields	array[string]			A list of OED fields used to group the generated losses.
summarycalc	boolean		default False	Legacy - (oasis 2.4.x and older) If true, output summary calculations by level for the summary set.
eltcalc	boolean		default False	Legacy - (oasis 2.4.x and older) If true, output the event loss table by level for the summary set.
aalcalc	boolean		default False	Legacy - (oasis 2.4.x and older) If true, output the average annual loss by level for the summary set.
aalcalcmeanonly	boolean		default False	Legacy - (oasis 2.4.x and older) If true, output the average annual loss by level for the summary set without calculating the standard deviation.
pltcalc	boolean		default False	Legacy - (oasis 2.4.x and older) If true, output the period loss table by level for the summary set.
lec_output	boolean		default False	Legacy - (oasis 2.4.x and older) If true, output loss exceed curves by level for the summary set.
leccalc	object			Legacy - (oasis 2.4.x and older) Specifies which loss exceedence curve types will be outputed for the summary level
ord_output	object			ORD output settings

ri_summaries.leccalc

Legacy - (oasis 2.4.x and older) Specifies which loss exceedence curve types will be outputed for the summary level

Field	Type	Required	Constraints	Description
return_period_file	boolean		default False	Legacy - (oasis 2.4.x and older) If true, a file listing the return periods will be provided as part of the analysis inputs. If false, a default set will be used.
full_uncertainty_aep	boolean		default True	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the full uncertainty aggregate loss exceedence curve by level for the summary set.
full_uncertainty_oep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the full uncertainty occurrence loss exceedence curve by level for the summary set.
wheatsheaf_aep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the wheatsheaf aggregate loss exceedence curve by level for the summary set.
wheatsheaf_oep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the wheatsheaf occurrence loss exceedence curve by level for the summary set.
wheatsheaf_mean_aep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the wheatsheaf mean aggregate loss exceedence curve by level for the summary set.
wheatsheaf_mean_oep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the wheatsheaf occurrence loss exceedence curve by level for the summary set.
sample_mean_aep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the sample mean aggregate loss exceedence curve by level for the summary set.
sample_mean_oep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the sample occurrence loss exceedence curve by level for the summary set.

ri_summaries.ord_output

ORD output settings

Field	Type	Required	Constraints	Description
elt_sample	boolean		default False	Sample Event Loss Table (ORD Output flag)
elt_quantile	boolean		default False	Quantile Event Loss Table (ORD Output flag)
elt_moment	boolean		default False	Moment Event Loss Table (ORD Output flag)
plt_sample	boolean		default False	Sample Period Loss Table (ORD Output flag)
plt_quantile	boolean		default False	Quantile Period Loss Table (ORD Output flag)
plt_moment	boolean		default False	Moment Period Loss Table (ORD Output flag)
alt_period	boolean		default False	Period Average Loss Table (ORD Output flag)
alt_meanonly	boolean		default False	Average Loss Table with no standard deviation calculation (ORD Output flag)
alct_convergence	boolean		default False	Average Loss Convergence Table (ORD Output flag), requires alt_period set to true
alct_confidence	number		default 0.95; minimum 0.0; maximum 1.0	Set confidence level for ALCT
ept_full_uncertainty_aep	boolean		default False	Exceedance Probability Table (option), when enable this metric is added to the EPT file
ept_full_uncertainty_oep	boolean		default False	Exceedance Probability Table (option), when enable this metric is added to the EPT file
ept_mean_sample_aep	boolean		default False	Exceedance Probability Table (option), when enable this metric is added to the EPT file
ept_mean_sample_oep	boolean		default False	Exceedance Probability Table (option), when enable this metric is added to the EPT file
ept_per_sample_mean_aep	boolean		default False	Exceedance Probability Table (option), when enable this metric is added to the EPT file
ept_per_sample_mean_oep	boolean		default False	Exceedance Probability Table (option), when enable this metric is added to the EPT file
psept_aep	boolean		default False	Per Sample Exceedance Probability Table, (option) when enable this metric is added to the PSEPT file
psept_oep	boolean		default False	Per Sample Exceedance Probability Table (option), when enable this metric is added to the PSEPT file
return_period_file	boolean		default False	If true, a file listing the return periods will be used for EPT and PSEPT files. If false, a default set will be used.
parquet_format	boolean		default False	Write output files in parquet format rather than csv format.

rl_summaries

Field	Type	Required	Constraints	Description
id	integer	Yes	minimum 1	Identifier for the summary set.
oed_fields	array[string]			A list of OED fields used to group the generated losses.
summarycalc	boolean		default False	Legacy - (oasis 2.4.x and older) If true, output summary calculations by level for the summary set.
eltcalc	boolean		default False	Legacy - (oasis 2.4.x and older) If true, output the event loss table by level for the summary set.
aalcalc	boolean		default False	Legacy - (oasis 2.4.x and older) If true, output the average annual loss by level for the summary set.
aalcalcmeanonly	boolean		default False	Legacy - (oasis 2.4.x and older) If true, output the average annual loss by level for the summary set without calculating the standard deviation.
pltcalc	boolean		default False	Legacy - (oasis 2.4.x and older) If true, output the period loss table by level for the summary set.
lec_output	boolean		default False	Legacy - (oasis 2.4.x and older) If true, output loss exceed curves by level for the summary set.
leccalc	object			Legacy - (oasis 2.4.x and older) Specifies which loss exceedence curve types will be outputed for the summary level
ord_output	object			ORD output settings

rl_summaries.leccalc

Legacy - (oasis 2.4.x and older) Specifies which loss exceedence curve types will be outputed for the summary level

Field	Type	Required	Constraints	Description
return_period_file	boolean		default False	Legacy - (oasis 2.4.x and older) If true, a file listing the return periods will be provided as part of the analysis inputs. If false, a default set will be used.
full_uncertainty_aep	boolean		default True	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the full uncertainty aggregate loss exceedence curve by level for the summary set.
full_uncertainty_oep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the full uncertainty occurrence loss exceedence curve by level for the summary set.
wheatsheaf_aep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the wheatsheaf aggregate loss exceedence curve by level for the summary set.
wheatsheaf_oep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the wheatsheaf occurrence loss exceedence curve by level for the summary set.
wheatsheaf_mean_aep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the wheatsheaf mean aggregate loss exceedence curve by level for the summary set.
wheatsheaf_mean_oep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the wheatsheaf occurrence loss exceedence curve by level for the summary set.
sample_mean_aep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the sample mean aggregate loss exceedence curve by level for the summary set.
sample_mean_oep	boolean		default False	Legacy - (oasis 2.4.x and older) If true and LEC output is true, output the sample occurrence loss exceedence curve by level for the summary set.

rl_summaries.ord_output

ORD output settings

Field	Type	Required	Constraints	Description
elt_sample	boolean		default False	Sample Event Loss Table (ORD Output flag)
elt_quantile	boolean		default False	Quantile Event Loss Table (ORD Output flag)
elt_moment	boolean		default False	Moment Event Loss Table (ORD Output flag)
plt_sample	boolean		default False	Sample Period Loss Table (ORD Output flag)
plt_quantile	boolean		default False	Quantile Period Loss Table (ORD Output flag)
plt_moment	boolean		default False	Moment Period Loss Table (ORD Output flag)
alt_period	boolean		default False	Period Average Loss Table (ORD Output flag)
alt_meanonly	boolean		default False	Average Loss Table with no standard deviation calculation (ORD Output flag)
alct_convergence	boolean		default False	Average Loss Convergence Table (ORD Output flag), requires alt_period set to true
alct_confidence	number		default 0.95; minimum 0.0; maximum 1.0	Set confidence level for ALCT
ept_full_uncertainty_aep	boolean		default False	Exceedance Probability Table (option), when enable this metric is added to the EPT file
ept_full_uncertainty_oep	boolean		default False	Exceedance Probability Table (option), when enable this metric is added to the EPT file
ept_mean_sample_aep	boolean		default False	Exceedance Probability Table (option), when enable this metric is added to the EPT file
ept_mean_sample_oep	boolean		default False	Exceedance Probability Table (option), when enable this metric is added to the EPT file
ept_per_sample_mean_aep	boolean		default False	Exceedance Probability Table (option), when enable this metric is added to the EPT file
ept_per_sample_mean_oep	boolean		default False	Exceedance Probability Table (option), when enable this metric is added to the EPT file
psept_aep	boolean		default False	Per Sample Exceedance Probability Table, (option) when enable this metric is added to the PSEPT file
psept_oep	boolean		default False	Per Sample Exceedance Probability Table (option), when enable this metric is added to the PSEPT file
return_period_file	boolean		default False	If true, a file listing the return periods will be used for EPT and PSEPT files. If false, a default set will be used.
parquet_format	boolean		default False	Write output files in parquet format rather than csv format.
